[Jun 28, 2026] H12-841_V1.5 Exam Brain Dumps - Study Notes and Theory
Pass Huawei H12-841_V1.5 Test Practice Test Questions Exam Dumps
NEW QUESTION # 61
(Which of the following statements about the underlay network of a VXLAN-based virtualized campus network isfalse?)
- A. When iMaster NCE-Campus is used to implement automatic orchestration of the routing domain on the underlay network, only OSPF single-area deployment is supported.
- B. When iMaster NCE-Campus is used to implement automatic orchestration of routing domains on the underlay network, only OSPF is supported.
- C. The underlay network provides IP reachability so that VXLAN-encapsulated service packets can be transmitted between VTEPs.
- D. The virtualized campus network solution introduces VXLAN technology, which uses MAC-in-UDP encapsulation to build a logical network over a traditional IP network.
Answer: B
Explanation:
Comprehensive and Detailed 200 to 250 words of Explanation From HCIP Datacom Campus Network documents knowledge without any URL or Links:
In a VXLAN-based virtualized campus network, theunderlay networkis responsible for providing basic IP connectivity between VXLAN Tunnel Endpoints (VTEPs). Statement D correctly describes this fundamental role of the underlay. Statement C is also correct, as VXLAN usesMAC-in-UDP encapsulationto overlay Layer 2 networks on top of a traditional IP infrastructure.
When iMaster NCE-Campus is used for automatic orchestration of the underlay routing domain,multiple routing protocols can be supported, depending on the solution version and design. Therefore, statementA is false, because OSPF is not the only supported routing protocol.
Statement B is correct in the context of standard automated deployment: iMaster NCE-Campus supports OSPF single-area deploymentfor simplified orchestration and maintenance of the underlay network.
According to HCIP Datacom Campus Network architecture principles, the underlay must be stable, simple, and highly available, but it is not limited to a single routing protocol. Thus,option Ais the incorrect statement and the correct answer.
NEW QUESTION # 62
In Huawei's WAN bandwidth management solution, which of the following functions can "classify and label traffic of different application types to provide a basis for subsequent QoS scheduling"?
- A. Deduplication
- B. Link aggregation
- C. Bandwidth quota allocation
- D. Application identification and tagging (e.g., DSCP tagging)
Answer: D
NEW QUESTION # 63
In an MPLS VPN network, when a PE device forwards VPN packets to a P device, if the PE device does not encapsulate a public network label, which of the following problems will occur?
- A. The PE device automatically re-encapsulates the public network label before forwarding.
- B. The CE device cannot receive data packets (VPN label missing).
- C. Data packets are forwarded normally to the target PE device without affecting services.
- D. The P device cannot identify the packet forwarding path and discards the packet.
Answer: D
NEW QUESTION # 64
In MPLS VPN network troubleshooting, if "the PE device has learned the remote CE route, but the local CE device still cannot ping the remote CE", which of the following troubleshooting steps should be performed first?
- A. Check if the MPLS LSP is established on the P device.
- B. Check if the operating system of the remote CE device is running normally.
- C. Check if the BGP VPNv4 neighbor between PE devices is established normally.
- D. Check if the IP address of the VPN instance interface on the local PE device is on the same network segment as the CE device.
Answer: D
NEW QUESTION # 65
In Huawei's SD-WAN solution, for the scenario of " multi-tenant branch sharing MPLS links", which of the following technologies can "achieve MPLS traffic isolation for different tenants and independently count bandwidth usage"?
- A. Create a separate VPN instance for each tenant and bind it to an MPLS interface sub-interface.
- B. Only total bandwidth usage is counted, without distinguishing between tenants.
- C. Traffic is segmented by tenant IP address range, without instance isolation.
- D. All tenants share the MPLS link, with no isolation or statistics.
Answer: A
NEW QUESTION # 66
In an MPLS VPN network, which of the following descriptions does NOT conform to the normal logic of "VPN routing and forwarding"?
- A. Data packets sent by the CE device first reach the PE device, where the PE device encapsulates a VPN label.
- B. After receiving the data packet, the remote PE device removes the public network label but retains the VPN label before forwarding it to the CE device.
- C. The data packets received by the CE device should be unlabeled IPv4/IPv6 data packets.
- D. PE devices transmit data packets carrying double tags via MPLS LSP.
Answer: B
NEW QUESTION # 67
In Huawei's WAN solution, which of the following technologies can enhance the reliability and efficiency of "cross-regional file transfer"? (Multiple choice)
- A. Adaptive bandwidth (adjusting the transmission rate according to link load to avoid congestion)
- B. Encrypted transmission (such as SSL/TLS encryption to ensure secure file transfer)
- C. Resume interrupted file transfer (if the file transfer is interrupted, it resumes from the point of interruption without restarting).
- D. No interrupted download; if interrupted, the entire file must be retransmitted.
- E. Transmitting files in plaintext poses a risk of data leakage .
Answer: A,B,C
NEW QUESTION # 68
(On a virtualized network deployed using iMaster NCE-Campus, after an administrator performs an operation, iMaster NCE-Campus delivers the following configuration to devices. Which of the following operations did the administrator perform?) acl number9997 rule1permit ip source ucl-groupnameResearch_Group destination ucl-groupnameSales_Group rule2permit ip source ucl-groupnameResearch_Group destination ucl-groupnameGuest_Group
- A. Create a security group.
- B. Create an authorization result.
- C. Deploy inter-VN communication.
- D. Deploy a policy control matrix.
Answer: D
Explanation:
In a virtualized campus network managed byiMaster NCE-Campus, traffic control between users or user groups is implemented throughsecurity groupsand apolicy control matrix. The configuration shown clearly reflects this mechanism.
The ACL usesucl-group names, such asResearch_Group,Sales_Group, andGuest_Group. These ucl-groups correspond tosecurity groupsdefined on iMaster NCE-Campus. The ACL rules explicitly permit IP traffic from one security group to other security groups. This type of ACL is automatically generated and delivered by the controller when apolicy control matrixis deployed.
A policy control matrix defineswho can access whomby specifying allow or deny relationships between security groups. Once the matrix is configured on iMaster NCE-Campus, the controller translates these logical policies into device-level ACLs and applies them to the appropriate enforcement points in the VXLAN fabric.
The presence of multiple rules permitting traffic from one group to multiple destination groups is a typical outcome of deploying such a matrix.
Creating a security group alone would not generate ACL rules. Deploying inter-VN communication would involve route exchange or gateway configuration, not ucl-group-based ACLs. Creating an authorization result would associate users with security groups but would not generate inter-group ACL rules.
Therefore, the administrator operation that resulted in this configuration wasdeploying a policy control matrix, making optionAthe correct answer.
NEW QUESTION # 69
In troubleshooting MPLS VPN networks, if it is necessary to "check the OSPF neighbor status between the PE device and the CE device to confirm whether the neighbor has been established normally", which of the following commands should be used?
- A. Display OSPF peer
- B. display bgp vpnv4 all peers
- C. display mpls lsp
- D. display ip routing-table vpn -instance
Answer: A
NEW QUESTION # 70
In troubleshooting MPLS VPN networks, if "MPLS LSPs have been established between PE devices, but VPN data still cannot be forwarded," which of the following troubleshooting steps should be performed first?
- A. Check the hardware status of the CE device.
- B. Check the binding relationship between VPN instances and interfaces on the PE device.
- C. Check if the physical links between PE devices are working properly.
- D. Check the MPLS protocol configuration on the P device.
Answer: B
NEW QUESTION # 71
In Huawei's SD-WAN solution, which of the following functions can "statistically calculate the traffic ratio of public network services and VPN services for each branch device and generate multi-dimensional traffic reports"?
- A. Business Traffic Classification Statistics and Reports
- B. Link Quality Detection (LQM)
- C. VPN tunnel status monitoring
- D. Equipment hardware resource monitoring
Answer: A
NEW QUESTION # 72
In Huawei's WAN bandwidth optimization solution, which of the following technologies can
"eliminate duplicate file blocks transmitted in the link and reduce bandwidth usage"?
- A. Deduplication technology
- B. Data compression technology
- C. Link aggregation technology
- D. Application-layer traffic shaping techniques
Answer: A
NEW QUESTION # 73
In an MPLS VPN network, when CE devices and PE devices exchange routes, which of the following protocols is NOT suitable for scenarios with "a large number of routes and frequent dynamic updates"?
- A. Static Routing
- B. OSPF
- C. RIP
- D. BGP
Answer: A
NEW QUESTION # 74
In the OSPF protocol for wide area networks, which of the following is the propagation range of
"ASBR Summary LSA (Type 4 LSA)"?
- A. Propagation in the area where the ASBR is located and its adjacent areas.
- B. Spreads only within the area where ASBR is located.
- C. Spreads only within the core area (Area 0)
- D. Propagate throughout the entire OSPF autonomous system (except NSSA areas)
Answer: D
NEW QUESTION # 75
In MPLS VPN network planning, which of the following components are the core elements for building an L3VPN (Layer 3 VPN)? (Multiple choice)
- A. CE equipment (Customer Edge)
- B. Physical leased line (can build a Layer 3 VPN without MPLS protocol )
- C. P equipment (Provider, backbone provider equipment)
- D. VLAN segmentation (only used for Layer 2 isolation, unrelated to Layer 3 VPN)
- E. PE device (Provider Edge)
Answer: A,C,E
NEW QUESTION # 76
In Huawei's WAN solution, for scenarios where " intermittent packet loss occurs in the WAN link," which of the following technologies can "ensure the reliability of data transmission through a retransmission mechanism"?
- A. Relies solely on link-layer retransmissions, without handling network-layer packet loss.
- B. Reduce the transmission rate to forcibly reduce the probability of packet loss.
- C. TCP-based retransmission mechanism (automatic retransmission of lost data packets)
- D. Ignoring packet loss and not performing any retransmission processing leads to data loss.
Answer: C
NEW QUESTION # 77
In the OSPF protocol for wide area networks, what is the function of Type 4 LSA (ASBR Summary LSA)?
- A. Describes router information within the network and propagates it within the area.
- B. Describes external routing information for the AS and propagates it throughout the AS.
- C. Describe summarized routes between areas to reduce routing table entries.
- D. Describes the location information of the ASBR, used by routers within the area to locate the ASBR.
Answer: D
NEW QUESTION # 78
In Huawei's WAN bandwidth optimization solution, for "cross-regional web browsing traffic (HTTP/HTTPS)," which of the following technologies can "accelerate webpage loading speed and reduce waiting time"?
- A. Directly transmit webpage data without any optimization.
- B. Reduce webpage resolution, sacrificing display quality for speed.
- C. Only increase link bandwidth without optimizing web page transmission mechanisms.
- D. Edge caching of static web page resources (such as images and JS files cached to edge nodes).
Answer: D
NEW QUESTION # 79
In Huawei's WAN bandwidth management solution, which of the following functions can achieve
"refined control of bandwidth resources" to avoid bandwidth abuse? (Multiple choice)
- A. Application bandwidth limiting (e.g., P2P download speed limited to 10Mbps)
- B. No bandwidth quota; all users share bandwidth, prone to congestion.
- C. Without bandwidth usage statistics, it is impossible to pinpoint the source of bandwidth abuse .
- D. Bandwidth usage statistics and report generation (bandwidth usage analysis by time/application)
- E. Bandwidth quotas based on users/departments (e.g., 100Mbps bandwidth allocated to the marketing department).
Answer: A,D,E
NEW QUESTION # 80
In a wide area network (WAN) IPv6 transition scenario, if "an enterprise needs to provide both IPv4 and IPv6 services to the outside world, but only deploys IPv4 internally," which of the following technologies should be adopted?
- A. Disable IPv6 service and only provide IPv4 service.
- B. IPv6 over IPv4 tunnel (only allows access from IPv6 terminals)
- C. IPv4/IPv6 dual-stack technology (internal devices must support IPv6)
- D. NAT464 (translates external IPv6 addresses into internal IPv4 addresses, allowing direct access from external IPv4 addresses)
Answer: D
NEW QUESTION # 81
Drag the user authentication results to the corresponding network access rights.
Answer:
Explanation:
Explanation:
* Position 1 # Before authenticationBefore users are authenticated, they are placed in thepre- authentication domain. At this stage, access is strictly limited to basic network services such as the Admission server,DHCP server, andDNS server. This allows users to obtain IP addresses and reach authentication-related services only.
* Position 2 # Upon authentication failuresIf user authentication fails or security posture checks (such as antivirus or patch verification) do not pass, users are redirected to theisolation domain. In this domain, access is restricted to remediation resources likevirus signature database serversandpatch servers, preventing users from accessing business services while allowing problem resolution.
* Position 3 # After successful authenticationAfter authentication succeeds, users enter thepost- authentication domain. At this stage, full or role-based access is granted to enterprise resources such as office data,R&D data,marketing systems, as well asintranet or Internet services, based on assigned policies.
This mapping reflects Huawei's standardNAC domain-based access control model, ensuring secure, staged network access.
NEW QUESTION # 82
In Huawei's WAN bandwidth management solution, which of the following functions can "allocate fixed bandwidth quotas based on departments or users to avoid bandwidth abuse"?
- A. Bandwidth quota management
- B. Data compression
- C. Application Traffic Shaping
- D. Deduplication
Answer: A
NEW QUESTION # 83
In the WAN BGP protocol, which of the following attributes can be used to "transmit route priority to IBGP neighbors, with a larger value indicating higher priority"?
- A. Next Hop
- B. MED
- C. AS_PATH
- D. Local Preference
Answer: D
NEW QUESTION # 84
(Huawei iMaster NCE-Campus provides the financial SD-WAN SRv6 solution to help the financial industry implement end-to-end scheduling. To use this function, you need to obtain the SRv6 function package license.)
- A. TRUE
- B. FALSE
Answer: A
Explanation:
Comprehensive and Detailed 200 to 250 words of Explanation From HCIP Datacom Campus Network documents knowledge without any URL or Links:
Huawei iMaster NCE-Campus supports advanced networking solutions tailored for industry-specific scenarios, including thefinancial SD-WAN SRv6 solution. This solution leverages Segment Routing over IPv6 (SRv6) to enable precise traffic steering, deterministic forwarding, and end-to-end service scheduling across the network.
Because SRv6 introduces enhanced forwarding capabilities and control-plane features beyond standard campus networking functions, Huawei licenses these capabilities separately. To activate SRv6-based financial SD-WAN features on iMaster NCE-Campus, customers must obtain theSRv6 function package license.
Without this license, SRv6-specific orchestration, scheduling, and optimization functions cannot be enabled.
According to HCIP Datacom Campus Network documentation, licensing ensures controlled feature activation and aligns with Huawei's modular service enablement strategy. Therefore, the statement is TRUE, and option A is correct.
NEW QUESTION # 85
......
